DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CAPC8056 F1G1C104A077 16V 100nF
S.M.CAPC8057 F1G1C104A077 16V 100nF
S.M.CAPC8100 F1G1E682A123 25V 6.8nF
S.M.CAPC8102 F1J1A475A087 10V 4.7µF
S.M.CAPC8104 F1H1C105A145 16V 1000nF
S.M.CAPC8106 F1G1C223A081 16V 22nF
S.M.CAPC8108 F1G1C104A077 16V 100nF
S.M.CAPC8110 F1G1C104A077 16V 100nF
S.M.CAPC8112 F1K1E106A136 25V 10µF
S.M.CAPC8114 F1K1E106A136 25V 10µF
S.M.CAPC8116 F1K1E106A136 25V 10µF
S.M.CAPC8118 F1K1E106A136 25V 10µF
S.M.CAPC8120 F1J0G2260001 4V 22µF
S.M.CAPC8122 F1J0G2260001 4V 22µF
S.M.CAPC8124 F1J0G2260001 4V 22µF
S.M.CAPC8126 F1J0G2260001 4V 22µF
S.M.CAPC8128 F1J0G2260001 4V 22µF
S.M.CAPC8200 F1G1C104A077 16V 100nF
S.M.CAPC8201 F1G1C104A077 16V 100nF
S.M.CAPC8202 F1G1C104A077 16V 100nF
S.M.CAPC8203 F1G1C104A077 16V 100nF
S.M.CAPC8204 F1G1C104A077 16V 100nF
S.M.CAPC8205 F1J1A106A087 10V 10µF
S.M.CAPC8206 F1G1C104A077 16V 100nF
S.M.CAPC8208 F1G1C104A077 16V 100nF
S.M.CAPC8210 F1G1C104A077 16V 100nF
S.M.CAPC8213 F1G1C104A077 16V 100nF
S.M.CAPC8214 F1J1A106A087 10V 10µF
S.M.CAPC8216 F1G1C104A077 16V 100nF
S.M.CAPC8218 F1G1C104A077 16V 100nF
S.M.CAPC8219 F1G1C104A077 16V 100nF
S.M.CAPC8222 F1G1C104A077 16V 100nF
S.M.CAPC8223 F1G1C104A077 16V 100nF
S.M.CAPC8224 F1G1C104A077 16V 100nF
S.M.CAPC8225 F1G1C104A077 16V 100nF
S.M.CAPC8226 F1G1C104A077 16V 100nF
S.M.CAPC8227 F1G1C104A077 16V 100nF
S.M.CAPC8300 F1G1H9R0A732 50V 9pF
S.M.CAPC8301 F1G1H8R0A732 50V 8pF
S.M.CAPC8302 F1G1C104A077 16V 100nF
S.M.CAPC8303 F1G1C104A077 16V 100nF
S.M.CAPC8304 F1G1C104A077 16V 100nF
S.M.CAPC8305 F1G1A105A047 10V 1000nF
S.M.CAPC8306 F1G1A105A047 10V 1000nF
S.M.CAPC8307 F1G1A105A047 10V 1000nF
S.M.CAPC8308 F1G1A105A047 10V 1000nF
S.M.CAPC8309 F1G1A105A047 10V 1000nF
S.M.CAPC8310 F1G1A105A047 10V 1000nF
S.M.CAPC8311 F1G1A105A047 10V 1000nF
S.M.CAPC8401 F1G1C104A077 16V 100nF
S.M.CAPC8402 F1K0J226A049 6.3V 22µF
S.
M
.CAPC8403 F1K0J226A049 6.3V 22µF
S.M.CAPC8406 F1G1C104A077 16V 100nF
S.M.CAPC8407 F1G1C104A077 16V 100nF
S.M.CAPC8411 F1G1C104A077 16V 100nF
S.M.CAPC8602 F1G1H390A565 50V 39pF
S.M.CAPC8603 F1J1A106A087 10V 10µF
S.M.CAPC8604 F1G1C104A077 16V 100nF
S.M.CAPC8605 F1G1C104A077 16V 100nF
S.M.CAPC8607 F1G1H100A565 50V 10pF
S.M.CAPC8608 F1G1H100A565 50V 10pF
S.M.CAPC8609 F1G1C104A077 16V 100nF
S.M.CAPC8611 F1G1C104A077 16V 100nF
S.M.CAPC8615 F1J1A106A087 10V 10µF
S.M.CAPC8616 F1J1A106A087 10V 10µF
S.M.CAPC8617 F1G1C104A077 16V 100nF
S.M.CAPC8619 F1G1C104A077 16V 100nF
S.M.CAPC8620 F1G1C104A077 16V 100nF
S.M.CAPC8621 F1G1H100A565 50V 10pF
S.M.CAPC8622 F1G1H100A565 50V 10pF
S.M.CAPC8624 F1G1H100A565 50V 10pF
S.M.CAPC8625 F1G1H100A565 50V 10pF
S.M.CAPC8626 F1G1H100A565 50V 10pF
S.M.CAPC8629 F1G1H390A565 50V 39pF
S.M.CAPC8630 F1G1H220A565 50V 22pF
S.M.CAPC8644 F1G1C104A077 16V 100nF
S.M.CAPC8714 F1J1A475A087 10V 4.7µF
S.M.CAPC8715 F1J1A106A087 10V 10µF
S.M.CAPC8716 F1G1C104A077 16V 100nF
S.M.CAPC8717 F1G1C104A077 16V 100nF
S.M.CAPC8724 F1J1A475A087 10V 4.7µF
S.M.CAPC8725 F1J1A475A087 10V 4.7µF
S.M.CAPC8764 F1J1A475A087 10V 4.7µF
S.M.CAPC8765 F1J1A475A087 10V 4.7µF
S.M.CAPC8900 F1G1C104A077 16V 100nF
S.M.CAPC8901 F1G1C104A077 16V 100nF
S.M.CAPC8902 F1G1C104A077 16V 100nF
S.M.CAPC8903 F1G1C104A077 16V 100nF
ELECTC9500 F2A1V4710079 35V 470µF
S.M.CAPC9501 F1K1H225A118 50V 2200nF
S.M.CAPC9502 F1H1C474A143 16V 470nF
S.M.CAPC9503 F1G1E1030005 25V 10nF
S.M.CAPC9505 F1G1E1030005 25V 10nF
S.M.CAPC9506 F1J1A475A087 10V 4.7µF
S.M.CAPC9507 F1H1C474A143 16V 470nF
S.M.CAPC9509 F1J1H182A721 50V 1.8nF
S.M.CAPC9510 F1J1H182A721 50V 1.8nF
S.M.CAPC9511 F1J1H182A721 50V 1.8nF
S.M.CAPC9512 F1J1H182A721 50V 1.8nF
S.M.CAPC9513 F1J1H182A721 50V 1.8nF
S.M.CAPC9514 F1J1H182A721 50V 1.8nF
S.M.CAPC
9515
F1J1H182A721 50V 1.8nF
S.M.CAPC9516 F1J1H182A721 50V 1.8nF
ELECTC9517 F2A2C5600001 160V 56µF
S.M.CAPC9518 F1G1E1030005 25V 10nF
S.M.CAPC9524 F1L2E1040002 250V 100nF
S.M.CAPC9601 F1K1H225A118 50V 2200nF
S.M.CAPC9602 F1H1C474A143 16V 470nF
S.M.CAPC9603 F1G1E1030005 25V 10nF
S.M.CAPC9605 F1G1E1030005 25V 10nF
S.M.CAPC9606 F1J1A475A087 10V 4.7µF
S.M.CAPC9607 F1H1C474A143 16V 470nF
ELECTC9617 F2A2C5600001 160V 56µF
S.M.CAPC9624 F1L2E1040002 250V 100nF
TERMINALS AND LINKS
15P CONNECTOR A02 K1KY15BA0324
A02-P2 WIRE A02-P2 TXJA02PKUE
7P CONNECTOR A10 K1KY07AA0719
A10-KA10 WIRE A10-KA10 TXJA10PKUE
4P CONNECTOR A12 K1KA04BA0055
A12-SPK WIRE A12-SP TXJA12PKUE
51P CONNECTOR A15 K1MY51B00004
LVDS FFC A15-CN5 TSXM420
14P CONNECTOR CN0100 K1KA14A00248
OPTICAL LINK D1006 K7AAAY000011
YUV,AUDI0 I/O JK1001 K1U710A00002
SCART TERMINAL JK1003 K1FY121A0012
PC TERMINAL JK1005 K1FY315A0009
HDMI TERMINAL JK1020 K1FY119D0015
HDMI TERMINAL JK1021 K1FY119D0015
HDMI TERMINAL JK1022 K1FY119D0015
USB TERMINAL JK1030 K1FY104A0020
USB TERMINAL JK1031 K1FY104A0020
ETHERNET TERMINALJK1040 K2LC1YYA0016
AV IN RCA JK1051 K1U306B00010
