Panasonic TX-L42E30E - Page 38

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
HP TERMINAL JK1052 K2HC1YYB0063
HDMI TERMINAL JK1061 K1FY119E0026
CI SLOT JK1070 K1NA68B00056
SD SLOT JK1080 K1NA12E00016
USB TERMINAL JK1090 K1FY104E0009
7P CONNECTOR KA10 K1KA07B00135
12P CONNECTOR LD2 K1KY12BA0322
14P CONNECTOR LD4 K1KY14BA0302
2P CONNECTOR P1 K1KA02B00295
16P CONNECTOR P2 K1KY16BA0311
14P CONNECTOR P4 K1KA14BA0311
P4-LD4 WIRE P4-LD4 TXJP04PKUE
PLUG ZA7001 K4AD01A00003
PLUG ZA7003 K4AD01A00003
SWITCHES
SWITCH SW7401 K0F122A00203
SWITCH SW7402 EVQ11G05R
SWITCH SW7403 EVQ11G05R
SWITCH SW7404 EVQ11G05R
SWITCH SW7406 EVQ11G05R
SWITCH SW7407 EVQ11G05R
DIFFERENCES FOR MODEL TX--L42E30E
EXPLODED VIEW
A P.C.B. 26 A-L42E30E
MODEL LABEL 27 TBM0E2498
INSTRUCTION BOOKS
GERMAN . TQB0E2097A
DUTCH . TQB0E2097B
ITALIAN . TQB0E2097C
FRENCH . TQB0E2097D
SPANISH . TQB0E2097E
SWEDISH . TQB0E2097F
NORWEGIAN . TQB0E2097G
FINNISH . TQB0E2097H
LITHUANIAN . TQB0E2097I
PORTUGUESE . TQB0E2097J
DANISH . TQB0E2097K
BULGARIAN . TQB0E2097M
ROMANIAN . TQB0E2097N
LATVIAN . TQB0E2097O
POLISH . TQB0E2097P
HUNGARIAN . TQB0E2097Q
CZECH . TQB0E2097R
GREEK . TQB0E2097S
TURKISH . TQB0E2097T
ENGLISH . TQB0E2097U
CROATIAN . TQB0E2097V
SLOVAKIAN . TQB0E2097W
CD . TQB0E2097X
ESTONIAN . TQB0E2097Z
I.C.s
EEPROM STM IC8901 STML42E30E
EEPROM LDA3 IC8902 X24CL42E30E
DIFFERENCES FOR MODEL TX--LF42E30
EXPLODED VIEW
A P.C.B. 26 A-LF42E30
MODEL LABEL 27 TBM0E2516
INSTRUCTION BOOKS
FRENCH . TQB0E2098D
ENGLISH . TQB0E2098U
I.C.s
EEPROM STM IC8901 STMLF42E30
EEPROM LDA3 IC8902 X24CLF42E30
DIFFERENCES FOR MODEL TX--LR42E30
EXPLODED VIEW
A P.C.B. 26 A-LR42E30
MODEL LABEL 27 TBM0E2517
INSTRUCTION BOOKS
KAZAKHSTAN . TQB0E21009
RUSSIAN . TQB0E2100L
UKRAINIAN . TQB0E2100Y
I.C.s
EEPROM STM IC8901 STMLR42E30
EEPROM LDA3 IC8902 X24CLR42E30
RTL
X
RTL
X
RTL
X
38
