Panasonic TX-W32D4F - Service Hints; Suggestions de Depannage; Location of Controls; Emplacement des Commandes

SERVICE HINTS SUGGESTIONS DE DEPANNAGE
HOW TO REMOVE THE REAR COVER COMMENT RETIRER LE PENNEAU ARRIÈRE
1. Remove the 10 screws (A) as shown in Fig.2. 1. Retirer les 10 vis (A) comme sur la Fig.2.
LOCATION OF CONTROLS EMPLACEMENT DES COMMANDES
4
SCREWS
VIS
Fig.2.
Focus
Screen
Y - Board
M - Board
E - Board D - Board
H - Board
F - Board
Fig.2.
