AV cable connection
Picture Quality
Best
Good
Basic
(Not
HD)
A
To use HDMI terminals
L
R
L
R
HDMI
AV OUT
HDMI-DVI
Conversion cable
DVI OUT
AUDIO OUT
e.g. Blu-ray Disc
player
e.g. Blu-ray Disc
player
AV Equipment
AV Equipment
B
To use COMPONENT input terminals
L
R
Y
P
B
PR
AUDIO
OUT
COMPONENT
VIDEO OUT
white
red
green
blue
red
white
red
red
blue
green
white
red
green
blue
red
e.g. Blu-ray Disc
player
AV Equipment
C
To use VIDEO input terminals
L
R
COMPOSITE
VIDEO OUT
yellow
white
red
yellow
white
red
yellow
white
red
or
e.g. DVD Recorder
AV Equipment
e.g. VCR
Audio connection
●
Listen to your TV through your stereo
DIGITAL
AUDIO IN
e.g. Amplifier
Optical cable
Stereo System
PC / Computer connection (VGA)
PC OUT
Computer
RGB PC
cable
Audio cable
Connect cable which matches the
audio out terminal on the computer
AUDIO OUT
Conversion adapter (if necessary)
