Specifications
123
Connection terminals
PC
HIGH-DENSITY D-SUB 15PIN
R,G,B: 0.7 V[p-p] (75 :)
HD, VD: TTL Level 2.0 – 5.0 V[p-p] (high impedance)
Applicable input signals:
VGA, SVGA, WVGA, XGA, SXGA, WXGA
Card slot
SD Card slot × 1
Common Interface slot (complies with CI Plus) × 1
ETHERNET RJ45, IEEE802.3 10BASE-T / 100BASE-TX
USB 1 / 2 / 3 USB2.0 DC 5 V, Max. 500 mA
DIGITAL AUDIO
OUT
PCM / Dolby Digital / DTS, Fibre optic
Built-in wireless
LAN
Standard
compliance and
Frequency range
3
IEEE802.11a/n
5.180 GHz - 5.320 GHz, 5.500 GHz - 5.580 GHz, 5.660 GHz - 5.700 GHz
IEEE802.11b/g/n
2.412 GHz - 2.472 GHz
Security WPA2-PSK (TKIP/AES) WPA-PSK (TKIP/AES) WEP (64 bit/128 bit)
Bluetooth wireless
technology
4
Standard
Compliance
Bluetooth 3.0
Frequency Range 2.402 GHz - 2.480 GHz
3D Eyewear (TY-ER3D4MA)
Dimensions (W × H × D) 167.7 mm × 42.2 mm × 170.7 mm
Mass Approx. 31 g
Lens type Liquid Crystal Shutter
Usage temperature range 0 °C - 40 °C
Battery
Coin-shaped lithium battery CR2025
Operation time: Approx. 75 hours in continuous use of the battery made by
Panasonic
Viewing range Within 3.2 m from front surface of the TV
Materials
Main body: Resin
Lens section: Liquid crystal glass
Communication system 2.4 GHz band FH-SS (Frequency Hopping Spread Spectrum)
1:
Energy consumption XYZ kWh per year, based on the power consumption of the television operating 4 hours per
day for 365 days. The actual energy consumption will depend on how the television is used.
2:
when the TV is turned off with the remote control and no function is active
3:
The frequency and channel differ depending on the country.
4:
Not all the Bluetooth compatible devices are available with this TV. Up to 5 devices can be used simultaneously
(except the 3D Eyewear and the VIERA Touch Pad Controller).
Note
Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate.
This equipment complies with the EMC standards listed below.
EN55013, EN61000-3-2, EN61000-3-3, EN55020, EN55022, EN55024
