Booster Power Amplifier
WA-BA240N
MAJOR OPERATING CONTROLS & TERMINALS
Front View
PREFACE
The WA-BA240N is a 240 W output monaural power
amplifier.
It includes 100 V and 70 V outputs for high-impedance
loudspeakers, as well as low-impedance loudspeaker output.
Inputs include LINE IN and 100 V.
Those who want to expand their high-impedance
loudspeakers but feel that the output of their main power
amplifier is insufficient can increase the output of their main
power amplifier to the 100 V input of the WA-BA240N.
This will provide output up to 240 W from the WA-BA240N,
which is enough to support speaker expansion. In addition,
operation mode/non-operation mode switching can be
performed externally when the WA-BA240N at a distance
from the main power amplifier.
The term "Amplifier" in this manual refers to the Panasonic
WA-BA240N Booster Power Amplifier.
Rear View
