CONNECTION OF THE HOB FOR PI3500:
*
calculated with the simultaneous factor following the standard EN 60 335-2-6
Connection of the hob
Setting up the configurations:
For the various kinds of connection, use the brass bridges which are in the box next the terminal
Monophase 230V~1P+N
Put the 1st bridge between terminal 1 and 2 and between 2 and 3, the 2nd between 4 and 5.
Attach the earth to the terminal “earth”, the neutral N to terminal 4 or 5, the Phase L to one of the
terminals 1, 2 or 3.
Biphase 400V~2P+N
Put the 1st bridge between terminal 1 and 2, the 2nd between 4 and 5.
Attach the earth to the terminal “earth”, the neutral N to terminal 4 or 5, the Phase L1 to the
terminals 1 or 2 and the Phase L2 to the terminal 3.
Triphase 400V~3P+N
Put a bridge between terminal 4 and 5.
Attach the earth to the terminal “earth”, the neutral N to terminal 4 or 5, the Phase L1 to the
terminals 1, the Phase L2 to the terminal 2 and the Phase L3 to the terminal 3.
Caution! Ensure that you correctly attach the wires and the bridges and tighten the screws
properly.
Mains Connection
Cable
diameter
Cable
Protection
calibre
230V~ 50/60Hz 1 Phase + N 3 x 4 mm²
H 05 VV - F
H 05 RR - F
40 A *
400V~ 50/60Hz 2 Phases + N 4 x 2.5 mm²
H 05 VV - F
H 05 RR - F
25 A *
400V~ 50/60Hz 3 Phases + N 5 x 1.5 mm²
H 05 VV - F
H 05 RR - F
16 A *
We cannot be held responsible for any incident resulting from incorrect connection or
which could arise from the use of an appliance which has not been earthed or h
equipped with a faulty earth connection.
