USER MANUAL
TDP43HET, TDP43HET/E,
TDP46HET,TDP46HET/E
B20733-02 Page 7 of 39 08-2022
Real time clock
○
○
Print Speed up to 12 ips (inches per second)
○
Print Speed up to 6 ips (inches per second)
○
1.3 General Specification
General Specifications
Physical dimensions
276 mm (W) x 326 mm (H) x 502 mm (D)
Weight
34 lb.
Electrical
Internal switching power supply
Input: 100~240VAC, 50/60Hz
Output: 24V, 8.33A, 200W
Environmental condition
Operation: 5 ~ 40˚C (41 ~ 104˚F), 25~85% non-condensing
Storage: -40 ~ 60 ˚C (-40 ~ 140˚F), 5~90% non-condensing
1.4 Print Specifications
Print
Specifications
TDP43HET
(300 dpi)
TDP46HET
(600 dpi)
Print head resolution
300 dots/inch
(12 dots/mm)
600 dots/inch
(24 dots/mm)
Printing method
Thermal transfer and direct thermal
Dot size
(width x length)
0.084 x 0.084 mm
(1 mm = 12 dots)
0.042 x 0.042 mm
(1 mm = 24 dots)
Print speed
(inches per second)
2-12 ips
ips selectable up to 12 ips
1-6 ips
ips selectable up to 6 ips
Max. print width
104 mm (4.09”)
Max. print length
1854.2 mm (73”)
1016 mm (40”)
1.5 Ribbon Specifications
Ribbon Specifications
Ribbon outside diameter
90 mm max.
Ribbon length
600 meter max.
Ribbon core inside diameter
1 inch (25.4 mm)
