Panther 55 - Mounting the Motor; Bolt-on Outboards

MOUNTING THE MOTOR
Bolt‐on Outboard
1. Thebracketispre-drilledtofitmostoutboardmotorbrackets.

2,Mountthemotortothebracketusing41/2inchstainlesssteelboltsoftheappropriatelength,together
withwashersonboltsidesasshown.Secureeachboltwithanylonlockingnut,makingsureyoughten
eachnutevenlyovertorquing.

3. IfyourmotorbracketdoesnotmatchthestandardBIAboltholepaern,you may drill addional holes
intothebrackettomatchthemounngholesofyourmotorbracket.


Clamp‐On Outboards
1. Usingatreatedwood2x4,cutawoodshimtoapproximately11incheslong.

2.Placetheshimontheinsideofthemounngplateandholditinplacewhile
placingthemotoroverthetopedgeofthebracket.
