62
4. Select printer SSID on direct interface to launch a connection invitation.
5. When the panel inquires if connect or not, click “OK” button for confirmation and Wi-Fi Direct.
Note:
• In case of auto connection mode, the mobile device will start to connect
automatically after initiating connection invitation without panel confirmation.
5.2.2.2. Connection method of wireless client that does not support Wi-Fi Direct
function (input password to connect)
1. Turn on printer power.
2. From printer control panel navigate to: " " -Network info-WiFi dir. info to check “Network
name” and “Password”
3. Turn on the computer or mobile device with wireless network function; select the SSID of Wi-Fi
Direct and input password to connect.
Note:
• Initial password of printer for Wi-Fi Direct: 12345678.
5.2.3. How to disable the Wi-Fi Direct
1. From printer control panel navigate to: " "-Network settings-Wi-Fi dir.
2. Select “Close” button and save.
5.3. Wireless network setup FAQs
1. The printer is not found.
• If the power of computer, access point (wireless router) or printer is turned on.
• If the computer is connected to printer with USB cable.
• If the printer supports wireless network connection.
2. SSID cannot be found when network is connected
• Inspect if the power switch of access point (wireless router) is turned on.
• The printer cannot find the SSID of the access point (wireless router) you need to connect,
please check the SSID of access point and try to connect again.
• Every time when the setup of access point (wireless router) is changed, you must set up the
wireless network of printer again.
3. Connection failure
• Please inspect if the safe mode and password of access point (wireless router) and printer is
correct.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pantum CM1100ADW and is the answer not in the manual?

Pantum CM1100ADW Specifications

General IconGeneral
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 600 DPI
Duplex printing modeAuto
Time to first page (black, normal)10 s
Time to first page (color, normal)11 s
Print speed (black, normal quality, A4/US Letter)18 ppm
Optional connectivityEthernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity1
Copier resize25 - 400 %
Duplex copyingNo
Maximum copy resolution600 x 600 DPI
Maximum number of copies99 copies
Time to first copy (black, normal)16 s
Time to first copy (color, normal)18 s
Scan toE-mail, FTP, PC, USB
Scanner typeFlatbed & ADF scanner
Image formats supportedJPEG, TIFF
Document formats supportedPDF
Optical scanning resolution300 x 300 DPI
Duplex functionsPrint
Maximum duty cycle30000 pages per month
Recommended duty cycle300 - 1500 pages per month
Number of print cartridges-
Total input capacity250 sheets
Total output capacity100 sheets
Multi-Purpose tray input capacity1 sheets
Envelopes sizesC5, C6, Com-10, DL, Monarch
Maximum print size216 x 356 mm
Paper tray media typesEnvelopes, Executive, Letterhead, Postcard
Paper tray media weight60 - 200 g/m²
Non-ISO print media sizes16K, Executive (184 x 267mm), Folio (media size), Legal (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)A5, A6
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 105 g/m²
Package depth555 mm
Package width535 mm
Package height456 mm
Package weight22100 g
Operating temperature (T-T)10 - 32 °C
Operating relative humidity (H-H)20 - 80 %
Mac operating systems supportedMac OS X 10.9 Mavericks, Mac OS X 12.0 Monterey
Linux operating systems supportedUbuntu 16.04, Ubuntu 18.04 LTS, Ubuntu 20.04 LTS, Ubuntu 22.04
Server operating systems supportedWindows Server 2012, Windows Server 2016, Windows Server 2016 x64
Windows operating systems supportedWindows 10, Windows 11, Windows 7, Windows 8, Windows 8.1, Windows XP
Power consumption (off)0.15 W
Power consumption (standby)10 W
Power consumption (average operating)380 W
Control typeTouch
Product colorWhite
Display diagonal3.5 \
Market positioningBusiness
Internal memory1000 MB
Sound pressure level (standby)30 dB
Sound pressure level (printing)52 dB
Sound pressure level (quiet mode)47 dB
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Weight and Dimensions IconWeight and Dimensions
Depth411 mm
Width401 mm
Height358 mm
