Pantum P2509 User Manual

4-3
4.2. Install the Printer to Network
1. Before starting the printer, rst connect the network cable to the network port of the printer
to establish direct connection to the network.
2. Start the printer and wait until the status indicator on the control panel displays Ready
status, as shown below.
3. Insert the printer CD into the computer. If the software installer does not start, browse to
the "setup.exe" le on the CD, and double-click to run the le.
4. Follow the operation instructions of the installer.
5. Continue to complete the installation.
Note: • When the installer p
rompts you to select a printer
, you can select the appropriate
printer name from the Detected Printer;
• If the printer name does not appear in the Detected Printer
, please click Refresh
and search for printers on the network;
• If you know the IP
address of the printer to be connected, you can select Specify
an IP Address for Installation to enter the IP
address for installation.
In this setting, the printer is directly connected to the network and can be set to allow all
computers on the network to print directly on the printer.

Pantum P2509 Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	150 sheets
Paper Output Capacity	100 sheets
Maximum Monthly Duty Cycle	15, 000 pages
Processor Speed	600 MHz
Memory	128 MB
Connectivity	USB 2.0
Duplex Printing	Manual
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	22 ppm (A4)
Media Sizes Supported	A4, A5, A6, Letter, Legal, Executive
Media Types Supported	Plain, Thick, Envelope, Label, Cardstock
Dimensions	337 x 220 x 178 mm
Toner Yield	1, 600 pages
Supported Paper Weight	60 - 163 g/m²
