PROGRAMMING INFO
30
IM738-738EX
BENCH TEST
(Refer to “Wiring Diagram” in the “Programming Guide”
1. To set zones in non-alarm state (keypad zone lights 5. [TRBL] key illuminates, due to timer loss.
off), install 1K OHM resistors across zone terminals. Push [TRBL] to view trouble conditions.
2. Connect keypad. Install 1K
OHM resistor across 6. All keypad lights except [TRBL] should be off and keypad
keypad zone. should respond to Master code arming and disarming.
3. Connect sounder or install 1K
OHM resistor across 7. Master Code:
default 474747.
"BELL" terminal.
4. Connect AC. Connect battery. 8. Keypad Programming
.
HEXA PROGRAMMING
(Used to program "Access to Upload/Download" and
"Installer Code")
All digits from 0 to F are valid. (See Interpreting Hexa Values)
Programming values are programmed into memory loca-
tions from address 000 to 043 and 300
to
527.
1) Press [
ENTER
] + installer code.
2) Key [
ENTER
] will flash (programming mode).
3) Enter 3 digit memory address.
4) Enter 2 digit data (See Hexa Display
to read value
).
5) Go to step 3 for next address.
To exit programming mode press [
CLEAR
].
STREAMLINED PROGRAMMING
(Used to program sections 00 to 67)
1) Press [
ENTER
] + installer code + [7].
2) Key [
ENTER
] and [2
ND
] will flash.
3) Enter 2 digit section number (00-67).
4) Enter 8 digits to program the section.
5)
Keypad will beep verifying data entry. Data is saved
and the next section is advanced to automatically.
6) Go to step 4 for next address.
7) To select a specific section, press [
CLEAR
] or
[
ENTER
] and go to step 3.
To exit programming mode press [
CLEAR
].
FEATURE SELECT PROGRAMMING
Feature selection programming addresses 062 to 126. The
"ON"/"OFF" status of the lights (keys) determines features
selected.
1) Press [
ENTER
] + installer code.
2) Key [
ENTER
] will flash.
3) Enter 3 digit memory address (062 to 126).
4) Press corresponding key to select option.
5) To change selection press key again.
6) To save press [
ENTER
].
7) Repeat steps 3 to 5 for addresses 062 to 126.
To exit programming mode press [
CLEAR
].
DECIMAL PROGRAMMING
Decimal value programming addresses 044 to 061. Values
entered must contain 3 digits.
1) Press [
ENTER
] + installer code.
2) Key [
ENTER
] will flash.
3) Enter 3 digit address (044 to 061).
4) Enter 3 digit DECIMAL value (See “Decimal Display”
to read value
).
5) Go to step 3 for next address.
To exit programming mode press [
CLEAR
].
