Esprit 728 Ultra & 738 Ultra - 6 - Programming Guide
* = Fire zone for 4-wire smoke detectors or 2-wire smoke detectors (with no ATZ enabled—728 Ultra only).
** = Fire zone for 2-wire smoke detectors (address 086, key [BYP]) only when ATZ is enabled (address 090, key [8]). Applies only to 728 Ultra.
† = Zones 1 to 10 for the 728 Ultra and Zones 1 to 18 for the 738 Ultra
Disarming (Opening) Report Codes (reset code “empty”): (continued)
Streamline
Section
Data Description Address
Streamline
Section
Data Description Address
___ / ___ User Code 13 364 ___ / ___ User Code 29 380
___ / ___ User Code 14 365 ___ / ___ User Code 30 381
___ / ___ User Code 15 366 ___ / ___ User Code 31 382
___ / ___ User Code 16 367 ___ / ___ User Code 32
383
___ / ___ User Code 17 368 ___ / ___ User Code 33 384
___ / ___ User Code 18 369 ___ / ___ User Code 34 385
___ / ___ User Code 19 370 ___ / ___ User Code 35 386
___ / ___ User Code 20 371 ___ / ___ User Code 36 387
___ / ___ User Code 21 372 ___ / ___ User Code 37 388
___ / ___ User Code 22 373 ___ / ___ User Code 38 389
___ / ___ User Code 23 374 ___ / ___ User Code 39 390
___ / ___ User Code 24 375 ___ / ___ User Code 40 391
___ / ___ User Code 25 376 ___ / ___ User Code 41 392
___ / ___ User Code 26 377 ___ / ___ User Code 42 393
___ / ___ User Code 27 378 ___ / ___ User Code 43 394
___ / ___ User Code 28 379 ___ / ___ User Code 44 395
___ / ___ User Code 45 396
___ / ___ User Code 46 397
___ / ___ User Code 47 398
___ / ___ User Code 48 /
(Duress)
399
Alarm Report Codes For Zones 1 to 10 (18) †: Alarm Restore Report Codes For Zones 1 to 10 (18) †:
Streamline
Section
Data Description Address
Streamline
Section
Data Description Address
___ / ___ Zone 1 400 ___ / ___ Zone 1 424
___ / ___ Zone 2 401 ___ / ___ Zone 2 425
___ / ___ Zone 3/Fire zone*
(fire address 100)
402 ___ / ___ Zone 3/Fire zone*
(fire address 100)
426
___ / ___ Zone 4 403 ___ / ___ Zone 4 427
___ / ___ Zone 5/Fire zone** 404 ___ / ___ Zone 5/Fire zone** 428
___ / ___ Zone 6 405 ___ / ___ Zone 6 429
___ / ___ Zone 7 406 ___ / ___ Zone 7 430
___ / ___ Zone 8 407 ___ / ___ Zone 8 431
___ / ___ Zone 9 408 ___ / ___ Zone 9 432
___ / ___ Zone 10 409 ___ / ___ Zone 10 433
___ / ___ Zone 11
(738 Ultra only) 410 ___ / ___ Zone 11 (738 Ultra only) 434
___ / ___ Zone 12
(738 Ultra only) 411 ___ / ___ Zone 12 (738 Ultra only) 435
___ / ___ Zone 13 412 ___ / ___ Zone 13 436
___ / ___ Zone 14 413 ___ / ___ Zone 14 437
___ / ___ Zone 15 414 ___ / ___ Zone 15 438
___ / ___ Zone 16 415 ___ / ___ Zone 16 439
___ / ___ Zone 17 416 ___ / ___ Zone 17 440
___ / ___ Zone 18
417
___ / ___ Zone 18 441
41 Future Use 418 - 423 47 Future Use 442 - 447
27
31
28
32
29
33
30
34
35
36
42
37
43
38
44
39
738 Ultra
only
45
738 Ultra
only
40
738 Ultra only
46
738 Ultra only
