Esprit 728 Ultra & 738 Ultra - 7 - Programming Guide
Zones 1 to 10 (18)† Shutdown Report Codes: Tampers 1 to 4, 5 and 7 (8)‡ Report Codes:
Streamline
Section
Data Description Address
Streamline
Section
Data Description Address
___ / ___ Zone 1 448 ___ / ___ Tamper 1 472
___ / ___ Zone 2 449 ___ / ___ Tamper 2 473
___ / ___ Zone 3 450 ___ / ___ Tamper 3 474
___ / ___ Zone 4 451 ___ / ___ Tamper 4 475
___ / ___ Zone 5 452 ___ / ___ Tamper 5 476
___ / ___ Zone 6 453 ___ / ___ Tamper 6
(738 Ultra only) 477
___ / ___ Zone 7 454 ___ / ___ Tamper 7 478
___ / ___ Zone 8 455 ___ / ___ Tamper 8
(738 Ultra only) 479
___ / ___ Zone 9 456 56 to 59 Future Use 480 - 495
___ / ___ Zone 10 457
___ / ___ Zone 11
(738 Ultra only) 458
___ / ___ Zone 12
(738 Ultra only) 459
___ / ___ Zone13 460
† = Zones 1 to 10 for the 728 Ultra and
Zones 1 to 18 for the 738 Ultra
___ / ___ Zone 14 461
___ / ___ Zone 15 462
‡ = Zones 1 to 4, 5 and 7 for 728 Ultra and
Zones 1 to 8 for 738 Ultra
___ / ___ Zone 16 463
___ / ___ Zone17 464
___ / ___ Zone 18 465
53 Future Use 466 - 471
Trouble Report Codes:
Streamline
Section
Data Description Address
Streamline
Section
Data Description Address
___ / ___ Max. aux. current 496 ___ / ___ Fire loop trouble 500
___ / ___ Bell disconnect /
max. bell current
497 ___ / ___ Timer loss 501
___ / ___ Battery disconnect /
low voltage
498 [2ND]/[2ND] Future Use 502
___ / ___ Power failure 499
[2ND]/[2ND] Future Use 503
Trouble Restore Report Codes:
Streamline
Section
Data Description Address
Streamline
Section
Data Description Address
___ / ___ Max. aux. current 504 ___ / ___ Fire loop trouble 508
___ / ___ Bell disconnect /
max. bell current
505 ___ / ___ Timer
programmed
509
___ / ___ Battery disconnect /
low voltage
506 ___ / ___ Tamper / wiring fault 510
___ / ___ Power failure 507 ___ / ___ TLM restore 511
Special Report Codes:
Streamline
Section
Data Description Address
Streamline
Section
Data Description Address
___ / ___ Test report 512 ___ / ___ Duress 520
___ / ___ Panic 1 513 ___ / ___
Closing Delinquency 521
___ / ___ Panic 2 514
[2ND]/[2ND] Future Use 522
___ / ___ Panic 3
515
[2ND]/[2ND] Future Use
523
___ / ___ Late to close 516 ___ / ___ Login (Espload) 524
___ / ___ No movement 517 ___ / ___ Program Change 525
___ / ___ Partial Arming 518
[2ND]/[2ND] Future Use 526
___ / ___ Recent Close 519
[2ND]/[2ND] Future Use 527
48
54
49
55
50
51
738 Ultra
only
52
738 Ultra only
60
61
62
63
64
66
65
67
