Paradox SP6000 Programming Guide

20
Magellan & Spectra SP • Programming Guide
Zone Labels
Use worksheet 13 to record your settings when programming zone labels.
Programmable Output Programming
Use the following section to program programmable outputs (PGMs) on your MG/SP control panel.
Programmable Output Recognition
NOTE: A wireless PGM module can be assigned to any PGM. These modules will work in parallel with the control panel output (not applicable to the SP4000).
Programmable Output on the K32LCD/K32LX
The on-board PGM of the K32LCD and K32LX (not programmable) will follow the arm status of any partition, via any arming method, including StayD. This only
applies to versions 5.10 and higher, with an ECO number of J014.
Worksheet 13: Zone Labels
Section Zone Zone Label Section Zone Zone Label
[181]
1 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[197]
17 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[182]
2 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[198]
18 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[183]
3 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[199]
19 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[184]
4 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[200]
20 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[185]
5 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[201]
21 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[186]
6 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[202]
22 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[187]
7 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[203]
23 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[188]
8 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[204]
24 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[189]
9 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[205]
25 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[190]
10 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[206]
26 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[191]
11 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[207]
27 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[192]
12 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[208]
28 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[193]
13 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[209]
29 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[194]
14 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[210]
30 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[195]
15 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[211]
31 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[196]
16 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[212]
32 __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
Table 11: Programmable outputs for MG/SP panels
PGM PGM Output
Control Panel
MG5000 MG5050 SP4000 SP5500 SP6000 SP65 SP7000
1 Control panel output 1 
2 Control panel output 2  - 
3 Control panel output 3 -  --Optional
4 Control panel output 4 -  --Optional-
5 Control panel relay - - - - Optional - 
6 ZX8/ZX82 ID = 1 output 
7 ZX8/ZX82 ID = 2 output 
8 ZX8/ZX82 ID = 3 output  -
9PGM4/PGM82 relay 1
10 PGM4/PGM82 relay 2 


11 PGM4/PGM82 relay 3 
12 PGM4/PGM82 relay 4 
13 RTX3/RX1 output 1 | PGM82 relay 5 - |  - 
14 RTX3/RX1 output 2 | PGM82 relay 6 - |  - 
15 RTX3 output 3 | PGM82 relay 7 - |  - 
16 RTX3 output 4 | PGM82 relay 8 Optional |  Optional Optional Optional Optional Optional Optional
