Magellan & Spectra SP • Installation Guide
| 9
Trouble Display
Your alarm system continuously monitors several trouble conditions that can be reported directly to your monitoring station. When a trouble condition occurs, the
[
TBL] key will illuminate. Press the [TBL] key, and the keypad will illuminate a number corresponding to the trouble the system is experiencing. Except for the Timer
Loss trouble, contact your monitoring station or installer to resolve the trouble condition.
NOTE: If the keypad emits a
BEEP every 5 seconds whenever a new trouble condition has occurred, press the [TBL] key to stop the “Trouble Beep”.
Accessing the Trouble Display
Press [TBL]
Key / LED Lit Trouble Type Trouble Details
[1] Wireless Zone Low Battery The batteries for one of the system’s wireless devices needs to be replaced.
[2] Power Trouble The control panel is experiencing power trouble.
[3] Bell Trouble There is a bell disconnect/overload on the control panel.
[4] Communication Trouble
Your alarm system, if monitored, could not communicate with the monitoring
station.
[5] Tamper/Zone Wiring Failure A wiring problem is occurring on one or more devices.
[6] Module Tamper Trouble A device’s anti-tamper switch has been triggered.
[7] Fire Loop Trouble One of the zones is in fire loop trouble.
[8] Timer Loss
Your alarm system’s clock must be reprogrammed. See Setting the Time and
Date on page 7 to set your system’s time and date.
[9] Wireless Zone Supervision Loss One or more wireless zones are no longer communicating with the system.
[0 (10)] Module Supervision Loss One or more modules are no longer communicating with the system.
[16] / [
SLEEP] Keypad Fault There is a problem with one of your system’s keypads
