8
Shorthand Instructions
Read the safety guidelines, page 2. After pressing the keys in the left column, the message in the center will appear. For more
detailed instructions, see page 5. Once familiar with the controller, you may prefer these shorthand instructions.
Single Segment Shorthand Instructions
Keys to Press Display Action
Turn power on IdLE (If different message appears, press START/STOP.)
START/STOP SPd1 - SPd5 Select a firing rate.
Up Arrow (not down) SPd 1 (Example of rate selected)
START/STOP °F or °C Enter target temperature.
Up&DownArrows 1900 (Example of temperature selected)
START/STOP Hd Enter hold time, if any.
Up&DownArrows 00.00 or hold time
START/STOP Strt
START/STOP dELA Enter delay time, if any.
Up&DownArrows 00.00 or Delay time
START/STOP -o n- The kiln is now firing.
Ramp-Hold Shorthand Instructions
Keys to Press Display Action
Turn power on IdLE (If different message appears, press START/STOP.)
START/STOP SPd1 - ProG Select “ProG” (program).
Up Arrow (not down) ProG
START/STOP Ra 1 Enter segment 1 rate.
Up&DownArrows 500 (example of rate selected)
START/STOP °F 1 or °C 1 Enter target temperature.
Up&DownArrows 1900 (example of temperature selected)
START/STOP Hd 1 Enter hold time, if any.
Up&DownArrows 00.00 or hold time
Continue entering values for the segments used. First segment not needed: enter a rate of 0000.
START/STOP Strt
START/STOP dELA Enter delay time, if any.
Up&DownArrows 00.00 or Delay time
START/STOP -o n- The kiln is now firing.
