Preparation of the vehicle for driving
54
9.1.1 Put the locking pin in the correct position
1. Remove the locking pin from the steering servo-motor. -> Press
and hold the internal button  of the locking pin. -> Pull out the
 locking pin.
2. Perform the "Align steering and steering servo-motor" work steps.

See Section "9.1.2 Align steering and steering servo-motor"
3. Connect and latch steering column and steering servo-motor. ->
Press and hold the  locking pin. -> Push the unlocking bolt 
forwards. -> Release the  locking pin.
Fig. 7: Locking pin position
