Operating the PARAVAN driving system
71
10.3.2 Steering joystick (2-way)

The steering joystick directly controls the steering actuator
motor. The movement of the joystick is converted to a steering
signal and executed by the steering actuator motor.
Move the joystick in the desired direction:
› The vehicle will execute the command.  The running wheels turn to
the right, follow a right bend.  The running wheels turn to the left,
drive a left bend.

See Section "7.1.2 Force adjustment of the operating elements"
Fig. 18: Steering joystick
