Pari Boy Pro - Compressor; Technical Data

6 TECHNICAL DATA
6.1 Compressor
General compressor data
Supply voltage[V]
Mains frequency[Hz]
Power consumption[A]
see label on confirmation of
purchase
Housing dimensions (W×H×D) 18.5cm×13.0cm×15.0cm
Weight 1.7kg
Pressure
5
1.6bar
Compressor flow
5
5.0 l/min.
Sound pressure level 54dB(A)
Classification according to IEC60601-1 /
EN60601-1
Type of electric shock protection Protection classII
Degree of protection from electric shock of
the applied part (nebuliser)
TypeBF
Degree of protection according to IEC60529/
EN60529 against penetration by water and
solid substances
IP 21
Degree of protection when used in the
presence of flammable mixtures of
anaesthetics with air, with oxygen, or with
nitrous oxide
No protection
Operating mode Continuous
operation
5) Towards PARI nebuliser nozzle (Ø0.48mm).
