Parker Hiross Hyperchill Plus ICEP024 User Manual

7.3 Techincal data
10
ICEP007-030
MODBUS
&)
unit adress

1
Default
Parametr
&)
BaudRate

9600
&)
Protocol Parity

1
&)
EVEN

NONE

ODD

Not configurable
Stop Bit

Data Bit

Address with offset 40000 (es: 8964+40000=48964)
Address Display label App type Default Min Max Unit Read Only Note
8964 Set INT 13(55,4) LIS 65(149) °C/(°F) FALSE Set point
8965 dIF1 INT 4(7,2) 0,3(0,5) 10(18) °C/(°F) FALSE Differential 1 for thermostating
8966 dIF2 INT 0,3(0,5) 0,3(0,5) 10(18) °C/(°F) FALSE Differential 2 for thermostating
8969 OFFC INT 2(3,6) ONC 10(18) °C/(°F) FALSE Differential for compressor OFF
8970 ONC INT 1(1,8) 0(0) OFFC °C/(°F) FALSE Dirrerential for compressor ON
8973 LiS INT 5(41) LA2 65(149) °C/(°F) FALSE Set point lower limit
8974 HA1 INT 60(140) -40(-40) 65(149) °C/(°F) FALSE B1 High terperature alarm
8975 LA1 INT -40(-40) -40(-40) 65(149) °C/(°F) FALSE B1 Low temperature alarm
8976 db1 INT 1(1,8) 1(1,8) 10(18) °C/(°F) FALSE B1 Low level temperature alarm retrigger
8977 HA2 INT 60(140) -40(-40) 65(149) °C/(°F) FALSE B2 High temperature alarm
8978 LA2 INT 2,5(36,5) -40(-40) 65(149) °C/(°F) FALSE B2 Low temperature alarm
8979 dI2 INT 4(7,2) 1(1,8) 10(18) °C/(°F) FALSE B2 Alarm differential
8980 HA3 INT 60(140) -40(-40) 65(149) °C/(°F) FALSE B3High temperature alarm
8981 LA3 INT -30(-22) -30(-22) 65(149) °C/(°F) FALSE B3 Low temperature alarm
8982 SEA INT 19(66,2) LIS 65(149) °C/(°F) FALSE Set point (B1) antifreeze
8983 dIA INT 1(1,8) 1(1,8) 10(18) °C/(°F) FALSE Thermostating differential (B1)
8984 ArA INT 5(41) -30(-22) 65(149) °C/(°F) FALSE Set point activation (B3)
8985 DtHA INT 5(9) 0(0) 30(54) °C/(°F) FALSE Differential for dipendent water exit regulation
8986 SRQH INT 30(86) -10(14) 55(131) °C/(°F) FALSE SetH point for control panel heater
8987 drq INT 19(34,2) 0(0) 30(54) °C/(°F) FALSE Differential control panel heater
8988 SrC INT 15(59) -30(-22) 50(122) °C/(°F) FALSE Setpoint Carter Heater
8989 drC INT 2(36) 0(0) 10(18) °C/(°F) FALSE Differential value for carter heater
8990 SRQL INT 5(41) -10(14) 30(86) °C/(°F) FALSE SetL point for control panel resistor
8995 PStA INT 0 0 1 TRUE Status ON/OFF dryer
8996 SUP BOOL FALSE FALSE TRUE FALSE Supervisor ON OFF request (to change the state machine - change True from "0" to "1")
16385 rE USINT 0 0 2 FALSE Remote ON/OFF enable
16387 SUP BOOL FALSE(0) FALSE(0) TRUE(1) FALSE ON/OFF enable from supervison
16384 C-F BOOL FALSE(0) FALSE(0) TRUE(1) FALSE Unit of measure (FALSE=°C, TRUE=°F)
16386 rAL USINT 0 0 2 FALSE Alarm relè management
16388 Ud4E BOOL FALSE(0) FALSE(0) TRUE(1) FALSE Enable antifreeze resistor 0=disabled
16390 ASt BOOL TRUE(1) FALSE(0) TRUE(1) FALSE Autostart enable 0=NO 1=YES
16391 r0n UINT 6 0 300 sec FALSE Main power supply return
16465 CPT BOOL FALSE(0) FALSE(0) TRUE(1) FALSE CPT control 1=Enable
16445 Erd BOOL FALSE(0) FALSE(0) TRUE(1) FALSE Enable managing water with Ambient temperature
8999 Dma INT 25(77) 0(32) 37(98,6) °C/(°F) FALSE Max value to stop compressor in ERD
8961 dMin INT 15(59) -20(-40) 37(98,6) °C/(°F) FALSE Min value to run compressor in ERD
16423 dAS USINT 5 0 10 Minutes FALSE Minimun time between two switch ON of the same compressor (minutes)
16431 tH1 INT 0 0 9999 KHours FALSE Compressor 1 working hours warning threshold (x1000)
16472 tH1L INT 0 0 9999 Hours FALSE Compressor 1 working hours warning threshold
16409 CHA1 BOOL TRUE(1) FALSE(0) TRUE(1) FALSE HA1 alarm management
16414 CHA2 BOOL TRUE(1) FALSE(0) TRUE(1) FALSE HA2 alarm management 0=Warning; 1=Alarm; 2=System
16411 CLA1 BOOL FALSE(0) FALSE(0) TRUE(1) FALSE LA1 alarm management
16419 rLa USINT 5 0 15 n° FALSE Max number of Events LA2 Alarm
16420 tLa USINT 60 5 60 Minutes FALSE Interval Time LA2 Alarm
16432 AbPd BOOL TRUE(1) FALSE(0) TRUE(1) FALSE Enable delay switching on pump
16433 dPOn USINT 15 dLE 60 Sec FALSE Delay switching ON pump (sec) at power on
