Parker Hiross Hyperchill Plus ICEP024 User Manual

Dimensional drawings ICEP030 (air)
17
ICEP007-030
1301
1405 MAX.
145
118
216
625 60
145 189
10(*) 1182(*) 10(*)
1202752
92(*) 568(*) 92(*)
1206 MAX.
756 MAX.
1202230
480
1234
12345678
A
B
C
D
E
F
A
B
C
D
E
F
CONDENSER AIR INLET INGRESSO ARIA CONDENS.
CONDENSER AIR OUTLET
USCITA ARIA CONDENS.
CONDENSER AIR INLET INGRESSO ARIA CONDENS.
CONDENSER COIL
AREA
AREA CONDENSATORE
WATER CONNECT.
ATTACCHI ACQUA
1"BSP-F
60Hz VERSION:
1"NPT-F WITH ADAPTERS
BLEED VALVE FOR CLOSED
CIRCUIT VERSION
VALVOLA DI SFIATO PER
VERSIONE A CIRCUITO CHIUSO
CIRCUIT WATER DISCHARGE
SCARICO ACQUA CIRCUITO
ELECTR.SUPPLY
CABLE INLET
INGRESSO CAVO
ALIM. ELETTR.
OUT
IN
(*) N°4 x 12
BASE FIXING HOLES POSITION
FORI FISSAGGIO BASE
1-WATER MANOMETER
2-LOW PRESSURE REFRIGERANT MANOMETER
3-HIGH PRESSURE REFRIGERANT MANOMETER
1
2
3
CIRCUITO APERTO
VERSIONE A
CARICO ACQUA PER
CIRCUIT VERSION
WATER CHARGE FOR OPEN

Parker Hiross Hyperchill Plus ICEP024 Specifications

General

Brand	Parker Hiross
Model	Hyperchill Plus ICEP024
Category	Chiller
Language	English
