18 ADP004-075
Model
dimensions (mm) - Fig. 4
A B C D C1 C2 E F G H I L M N
ADP004 550 1140 393 715 303 52 453 30 480 567 511 254 546 289
ADP006 690 1315 503 855 353 177 528 40 616 636 649 312 686 349
ADP009 936 1315 495 1173 345 206 528 47 850 658 895 304 932 341
ADP014 1036 1551 600 1273 400 200 678 44 950 743 994 358 1032 396
ADP018 1130 1869 660 1640 460 230 867 85 1301 875 1080 410 1126 456
Model air in/out
FR+L
connections
weight volume nominal air ow
pneumatic motor
air consumption
air pressure
matching
separator
(kg)* (dm
3
)* m
3
/min (1) m
3
/min (2) (bar)
ADP004
threaded
1½” BSP
3/8" F
37 3.7 3.5 0.15
16
STH013
ADP006 58 4 6 0.2
ADP009
threaded
2” BSP
70 6.6 9 0.4
STH021ADP014 106 9.1 14 0.5
ADP018
anged
PN16 DN80
(UNI 2278-67)
1/2" F 146 17.6 18 0.8
* Weight and volume are for a ercooler only; for separator see respective manual.
(1) 7 barg; 120°C inlet; air suction conditions: 0 m.a.s.l., 20°C, 50%; di erence between ambient and air outlet = 10°C.
(2) Data valid for 1400 rpm.
