Parker 890 Series User Manual

Bulletin HY25-1890-M1/US
Owner’s Manual
10-Bolt Extended Shaft PTOs
Parker Hannifin Corporation
Chelsea Products Division
Olive Branch, MS 38654 USA
21
Installation Sketches
Lube Hose Installation (SK-599)
897/899 Series
Units built on or after February 22, 2016
Serial Number 6053**** & greater
Lube Hose Installation (SK-492 Rev C)
897/899 Series
Units built on or prior to February 19, 2016
Serial Number 6050**** & less than
Transmission Pressure Hose
Included in Hose & Bracket Kit
Per Mounting Option
Torque End Fittings
to 11-12 lbs-ft
379486 90° Elbow Install in
Transmission High Pressure Port
MD: Left or Right Side
HD: Left Side Only
Torque Nut to 13-15 lbs-ft
379486
500841-1 90° Elbow Torque to 8-12 lbs-ft
379964 Adapter w/Restriction Torque to 8-12 lbs-ft
Wet Spline Hose Included In Hose &
Bracket Kit Per Mounting Option Torque
End Fittings to 11-12 lbs-ft
Transmission Pressure Hose
Included In Hose & Bracket Kit
Per Mounting Option Torque End
Fittings to 11-12 lbs-ft
379486 90° Elbow Install In
Transmission High Pressure Port
MD: Left or Right Side
HD: Left Side Only
Torque Nut to 13-15 lbs-ft
Fitting
WARNING: Restriction
Required to Prevent
Damage to PTO,
Transmission and
Hydraulic Pump
This symbol warns of possible personal injury.
