Parker AC10 - Parameters - Overview; Parameters to Set before Use

Easy Start Guide
Page 5
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
4. Parameters - overview
Parameter
Description
How to set
F111
Maximum Frequency (Hz)
Maximum frequency for the Inverter. Default is which suits most applications.50
F112
Minimum Frequency (Hz)
Minimum frequency for the Inverter. Default is which suits most applications.0.5
F114
First Acceleration Time (s)
Default is seconds; increase or decrease if faster or slower acceleration is required.5
F115
First Deceleration Time (s)
Default is seconds; increase or decrease if faster or slower deceleration is required.5
F137
Torque Compensation Mode
Default is ; can be set to 1 for centrifugal fan and pump applications.auto
F153
Carrier Frequency
Setting is rating dependent. Only change if required; default will suit most applications.
F200
Start Command Source
Default is for keypad + terminal + MODBUS (any input source).4
F201
Stop Command Source
Default is for keypad + terminal + MODBUS (any input source).4
F203
(desired motor speed in Hz)
Frequency Command Source
F113 is adjusted by the keypad and stored. No need to change either F113 or F203.
Default is 'Memory' which is set by parameter F113;
F209
Stopping Mode
Default is , ramped stop. Change to 1 for coast stop; this may suit some fan loads.0
F220
Frequency Memory
Default is ; can be set to 1 to store the keypad setpoint (F113) during power down.0
F228
Application Selection
Defaults below are based on F228 = 0
Default is ; will suit most applications. 5 different application Macros available.0
F801
Rated Motor Power (kW)
Rated kW of the motor. Set to match the motor nameplate eg. (2.2kW)2200
F802
Rated Motor Voltage (V)
Rated Voltage of the motor. Set to match the motor nameplate eg V230
F803
Rated Motor Current (A)
Rated current of the motor. Set to match the motor nameplate eg A2.4
F805
Base Motor rpm
Once this is set, read-only parameter F804 (number of motor poles) will be recalculated.
Rated rpm of the motor. Set to match the motor nameplate eg rpm (min-1)1460
F810
Motor rated Freq
Rated frequency of the motor. Default is Hz; change to suit the motor.50
Parameters are typically referred to by code or
number (eg. F803 = Rated Motor Current) with
a description available in the manual.
The Inverter contains a number of settings
which can be changed to tailor it for use in a
wide range of applications. These settings are
known as parameters.
The parameters contain critical information
essential to the correct operation of the
Inverter. Therefore, they should at least be
checked by the user before the Inverter is
operated for the first time.
The parameters listed in section 5 are intended
to provide a starting point to allow for basic
operation of theAC10 Inverter.
5. Parameters to set before use
See section 6 to learn how to set a parameter value.
Set the following parameters to allow the AC10
to control a motor with Run, Stop and Speed
Control from the keypad.
If any of the parameters have been changed
previously, follow the procedure in section 14
to reset the Inverter to Factory Defaults.
5.1 Parameters to check and values to set
Parker AC10 Series Inverter (to 22kW)
