Parker HTG Series User Manual

Service Manual
HTG Series Integrated Hydrostatic Transmission
23
Parker Hannin Corporation
Hydraulic Pump/Motor Division
Greeneville, Tennessee USA
HY13-1524-002-M1/US
General Information
Service Kit Information (page 1 of 3)
SK000275
HTG SERVICE KIT, FAN (8.3” Fan)
Item
QTY Part Number Description
1
1 25164 Nut
2
1 477370 Fan Spacer
3
1 420067 Fan (8.3”)
1 SK000275 Sheet 3 Service Bulletin
SK000276
HTG SERVICE KIT, MOTOR (240cc- Right Hand Side)
Item
QTY Part Number Description
1
1 TG0240SD081HTAA SA, Motor
2
2 032202-116 Packing, Preformed, O-Ring Seal
3
1 034009 Gasket, Side Cover
4
1 SK000276 Service Bulletin
SK000277
HTG SERVICE KIT, MOTOR (280cc- Right hand Side)
Item
QTY Part Number Description
1 1 TG0280SD081HTAA SA, Motor
2 2 032202-116 Packing, Preformed, O-Ring Seal
3 1 034009 Gasket, Side Cover
4 1 SK000277 Sheet 3 Service Bulletin
SK000278
HTG SERVICE KIT, MOTOR (310cc- Right hand Side)
Item
QTY Part Number Description
1 1 TG0310SD081HTAA SA, Motor
2 2 032202-116 Packing, Preformed, O-Ring Seal
3 1 034009 Gasket, Side Cover
4 1 SK000278 Sheet 3 Service Bulletin
SK000279
HTG SERVICE KIT, MOTOR (240cc- Left hand Side)
Item
QTY Part Number Description
1 1 TG0240SD080HTAA SA, Motor
2 2 032202-116 Packing, Preformed, O-Ring Seal
3 1 034009 Gasket, Side Cover
4 1 SK000279 Sheet 3 Service Bulletin
SK000280
HTG SERVICE KIT, MOTOR (280cc- Left hand Side)
Item
QTY Part Number Description
1 1 TG0280SD080HTAA SA, Motor
2 2 032202-116 Packing, Preformed, O-Ring Seal
3 1 034009 Gasket, Side Cover
4 1 SK000280 Sheet 3 Service Bulletin
SK000281
HTG SERVICE KIT, MOTOR (310cc- Left hand Side)
Item
QTY Part Number Description
1 1 TG0310SD080HTAA SA, Motor
2 2 032202-116 Packing, Preformed, O-Ring Seal
3 1 034009 Gasket, Side Cover
4 1 SK000281 Sheet 3 Service Bulletin
