Parker HTG Series User Manual

Service Manual
HTG Series Integrated Hydrostatic Transmission
24
Parker Hannin Corporation
Hydraulic Pump/Motor Division
Greeneville, Tennessee USA
HY13-1524-002-M1/US
General Information
Service Kit Information (page 2 of 3)
SK000282
HTG SERVICE KIT, BRAKE (5 Bolt Drum)
Item
QTY Part Number Description
1
1 040204 Cotter Pin
2
1 490164 Brake Assembly
4
1 490216 Drum Assembly
3
4 020207 Flange Head Screw
4
1 025113 Castle Nut
5
1 SK000281 Sheet 3 Service Bulletin
SK000283
HTG SERVICE KIT, BRAKE (4 Bolt Drum)
Item
QTY Part Number Description
1
1 040204 Cotter Pin
2
1 490164 Brake Assembly
4
1 490218 Drum Assembly
3
4 020207 Flange Head Screw
4
1 025113 Castle Nut
5
1 SK000283 Sheet 3 Service Bulletin
SK000284
HTG SERVICE KIT, BRAKE (5 Bolt Drum)
Item
QTY Part Number Description
1
1 040204 Cotter Pin
2
1 490169 Brake Assembly
4
1 490216 Drum Assembly
3
4 020207 Flange Head Screw
4
1 025113 Castle Nut
5
1 SK000284 Sheet 3 Service Bulletin
SK000285
HTG SERVICE KIT, BRAKE (4 Bolt Drum)
Item
QTY Part Number Description
1
1 040204 Cotter Pin
2
1 490169 Brake Assembly
4
1 490218 Drum Assembly
3
4 020207 Flange Head Screw
4
1 025113 Castle Nut
5
1 SK000285 Sheet 3 Service Bulletin
SK000287
HTG SERVICE KIT, SEAL TOP HOUSING (Gasket Kit inc. rubber & composite pan gaskets)
Item
QTY Part Number Description
1
1 401114 Retaining Ring
2
1 478086 Shaft Seal
3
1 478087 Seal Trunnion Arm
4
2 032202-116 Packing Preformed O-Ring Seal
5
1 032202-244 Packing Preformed O-Ring Seal
6
1 034007 Bottom Cover Composite Gasket
7
1 034009 Side Cover FE Gasket
8
1 034008 Bottom Cover FE Gasket
9
2 032203-114 Packing Preformed O-Ring Seal
10
1 032202-013 Packing Preformed O-Ring Seal
11
1 SK000287 Sheet 3 Service Bulletin
