Parker HTG Series User Manual

Service Manual
HTG Series Integrated Hydrostatic Transmission
25
Parker Hannin Corporation
Hydraulic Pump/Motor Division
Greeneville, Tennessee USA
HY13-1524-002-M1/US
General Information
SK000288
TG SERVICE KIT, MOTOR SERVICE (Motor Seal Kit)
Item
QTY Part Number Description
1
1 478035 Dirt & Water Seal
2
1 028515 Backup Ring
3
1 029118 Backup Washer
4
1 032818 Shaft Seal
5
3 032820 Viton Section O-Ring
6
2 032862 Section O-Ring
7
1 032861 Seal Ring
8
1 032202-244 O.D. End Cover O-Ring Seal
9
2 032202-116 Motor to Endblock O-Ring Seal
10
1 034009 Gasket Side Cover
11
1 SK000288 Sheet 3,4,5 Service Bulletin
SK000345
HTG SERVICE KIT, FAN (HTG 7.8")
Item
QTY Part Number Description
1 1 025164 Fan Nut
2 1 477370 Fan Spacer
3 1 420142 Fan 7.8”
4 1 SK000345 Sheet 3 Service Bulletin
SK000448
HTG HYDRAULIC TRANSMISSION OIL/ FILTER KIT- 2 GAL
Item
QTY Part Number Description
1 2 022078 Hex Head Screw
2 2 029130 Washer
3 2 406030 HT-1000 Oil (Gal)
4
2 411135S Filter (Service)
5
1 SK000448 Sheet 3,4,5,6 Service Bulletin
SK000456
HTG SERVICE KIT SEAL TOP HOUSING- FE Top Housing Gasket
Item
QTY Part Number Description
1
1 401114 Retaining Ring
2 1 478086 Shaft Seal
3 1 032202-244 Packing Preformed O-Ring Seal
4 1 032202-116 Packing Preformed O-Ring Seal
5 2 034009 Side Cover Gasket
6 1 034008 Bottom Cover FE Gasket
7 1 032203-114 Packing Preformed O-Ring Seal
8 2 032202-013 Packing Preformed O-Ring Seal
9 1 478087 Seal Trunnion Arm
10 1 SK000456 Sheet 3,4 Service Bulletin
Service Kit Information (page 3 of 3)
