17
WARNING: This product can expose you to chemicals including lead or DEHP which are known to the state of California to cause cancer,
birth defects, and other reproductive harm. www.p65warnings.ca.gov
Catalog HY13-PMD600-SM/US
PGP/PGM 600 Series
Gear Pumps & Motors Service Manual
Assembly Instructions
19) Torque diagonally opposed fasteners to correct
torque. (Fig. 21).
Do not lubricate fastener threads before assembly.
Follow torque guide below.
600 Series Torque Guide
Series Lbs-ft
PGP610/PGM610 43
PGP620/PGM620 70
PGP625/PGM625 70
PGP640/PGM640 103
Figure 21
