Parker PSE - Probes; Configuration

English
7/12
PSE 120-350
Symbol Function
Touch to view the thresholds of the analogue out-
put of the dew point “LB1 / HB1”,
Touch to con gure: the unit of measure; local / re-
mote start and alarm signaling “,
Touch to con gure the drain
Touch to see the working hours and time of the
next scheduled maintenance.
Touch to con gure the dryer
Touch to reset the alarm.
Probes
Touch the button
to enter
these parameters are available for reading / writing, it is possible to
change: the minimum / maximum dew point thresholds at the analog
output (4 ... 20mA) and the high dew point warning threshold.
To modify the parameter, touch the value, as shown in the  gure.
The keyboard used to dial the new desired value appears
Confi guration
Touch the button
to enter
touch the button to go ahead
these parameters are all changeable: unit of measure (C ° or F °); local or
remote start; alarm warning and restoring the default parameters.
To modify the parameter, touch the value, as shown in the  gure.
Choose your options.
(eg “C ° or F °”, or “Local on or rOFF”)
to activate it, touch the box in the  gure.
To return to the default parameters, touch as indicated in the  gure
The parameters are reset automatically.
