13
When powered up and connected the Sensor Status LEDs on the front of the Module
are colored as follows:
 Green = Connected
 Red = Disconnected
 Yellow = Connected but not calibrated.
If the LED shows Yellow, it’s time to replace the affected Sensor with a new one.
Connecting the wrong type of Sensor to the module also results in a Yellow indication.
Sensor 1
Sensor 2
Sensor 3
DIN Rail locking clip
