Parker SciLog DINCon - Dintemp Registers

25
DINTemp Register List:
ADDRESS ACCESS FORMAT VALUE DEFAULT
90-99 R ASCII String DINTemp Serial Number
100 R 16 bit Model Number
2
2 = DINTemp
101-102 R IEEE Float Software Version
103 R/W 16 bit Reset Control
bit 0 = System Reset
bit 1 = Reset to Defaults
bit 2 = Alarm Reset
104-105 R/W 16 bit Modbus Address
104 must be set to 0xa55a
0xa55a
registers 104-109 must be written as a block
105 contains Modbus address
30
106 R/W 16 bit Modbus Mode
0
0 = RS485 RTU
1 = RS485 ASCII
2 = RS232 RTU
3 = RS232 ASCII
4 = USB RTU
5 = USB ASCII
6 = TCP
107 R/W 16 bit Modbus Baud Rate (115200 Default)
8
0 = 1200
1 = 2400
2 = 4800
3 = 9600
4 = 19200
5 = 28800
6 = 38400
7 = 57600
8 = 115200
108 R/W 16 bit Modbus Serial Word Length (7 or 8)
8
109 R/W 16 bit Modbus Serial Parity (Even, 1 Stop Bit default)
2
0 = none, 2 Stop Bits
1 = odd, 1 Stop Bit
2 = even, 1 Stop Bit
110 R/W 16 bit TCP Address P1
192
111 TCP Address P2
168
112 TCP Address P3
0
113 TCP Address P4
144
