24
1 = 3/8" Barb
2 = 1/2" Barb
3 = 3/4" TC
4 = 1" TC
100 = Cal Fixture
282 R/W 16 bit P3 Sensor ID Material
0 = Polypropylene
1 = Polysulfone
283 R/W 16 bit P3 Sensor ID Month
284 R/W 16 bit P3 Sensor ID Year
285 R/W 16 bit P3 Sensor ID Lot
286 R/W 16 bit P3 Sensor ID Unit Number
288 R/W IEEE Float P3 Sensor Pressure Offset (PZ)
290 R/W IEEE Float P3 Sensor Cal Factor (CF)
292 R/W IEEE Float P3 Sensor Cal Pressure (CP1)
294 R/W IEEE Float P3 Sensor Cal Factor 2 (CF2)
296 R/W IEEE Float P3 Sensor Cal Pressure 2 (CP2)
300 R/W 16 bit P3 Sensor Custom Cal Status
bit 0 = Invalid
bit 1 = Start Zero
bit 2 = Start Span
bit 6 = Cal in Progress
bit 7 = Write Cal Data
301 R/W IEEE Float P3 Sensor Custom Pressure Offset (CPZ)
303 R/W IEEE Float P3 Sensor Custom Cal Factor (CCF)
315 R/W IEEE Float P3 Sensor Max Pressure
317 R/W 16 bit P3 Sensor MaxP, Day
318 R/W 16 bit P3 Sensor MaxP, Month
319 R/W 16 bit P3 Sensor MaxP, Year
