Parker SciLog DINCon User Manual

26
114 R/W 16 bit TCP Mask P1
255
115 TCP Mask P2
255
116 TCP Mask P3
255
117 TCP Mask P4
0
118 R/W 16 bit TCP Gateway P1
192
119 TCP Gateway P2
168
120 TCP Gateway P3
0
121 TCP Gateway P4
1
130 R/W 16 bit RTCC Control
bit 0 = Set Clock Values
Registers 130-137 must be written as a block
131 R/W 16 bit Day of Week (1-7)
132 R/W 16 bit Month
133 R/W 16 bit Day
134 R/W 16 bit Year
135 R/W 16 bit Hour (24)
136 R/W 16 bit Minute
137 R/W 16 bit Second
140 R/W 16 bit Temperature Units
0
0 = C
1 = F
141-142 R/W IEEE Float
Cal Temperature (Default 25C)
(Only change for use with a Custom Calibration)
25.0
150 R 16 bit T1 Status
bit 0 = Disconnected
bit 1 = Uncalibrated
bit 2 = Low Alarm
bit 3 = High Alarm
bit 6 = Cal in Progress
151-152 R IEEE Float T1 Temperature Value
153 R 16 bit T2 Status
bit 0 = Disconnected
bit 1 = Uncalibrated
bit 2 = Low Alarm
bit 3 = High Alarm
bit 6 = Cal in Progress
154-155 R IEEE Float T2 Temperature Value
156 R 16 bit T3 Status
bit 0 = Disconnected
bit 1 = Uncalibrated
bit 2 = Low Alarm
bit 3 = High Alarm
