19
bit3 = high alarm
154-155 R IEEE Float Temperature Value
160-161 R/W IEEE Float Conductivity Alarm Limit - Low
0.0
162-163 R/W IEEE Float Conductivity Alarm Limit - High
0.0
164-165 R/W IEEE Float Temperature Alarm Limit - Low
0.0
166-167 R/W IEEE Float Temperature Alarm Limit - High
0.0
180 R/W IEEE Float Temperature Reference
25.0
182 R/W IEEE Float Temperature Coefficient
1.90
184 R/W IEEE Float Temperature Offset
186 R/W 16 bit Temperature Comp. Disabled if NZ
0.0
201 R/W 16 bit Sensor ID Type
0 = Luer
1 = 3/8" Barb
2 = 1/2" Barb
3 = 3/4" TC
4 = 1" TC
100 = Cal Fixture
202 R/W 16 bit Sensor ID Material
0 = Polypropylene
1 = Polysulfone
203 R/W 16 bit Sensor ID Month
204 R/W 16 bit Sensor ID Year
205 R/W 16 bit Sensor ID Lot
206 R/W 16 bit Sensor ID Unit Number
208 R/W IEEE Float Sensor Temperature Offset (TO)
210 R/W IEEE Float Sensor Cal Factor (CCF)
220 R/W 16 bit Sensor Custom Cal Status
bit 0 = Invalid
bit 2 = Start Cal
bit 6 = Cal in Progress
bit 7 = Write Cal Data
221 R/W IEEE Float Sensor Custom Temperature Offset (CTO)
223 R/W IEEE Float Sensor Custom Cal Factor (CCF)
