6
IE NI
and safety instructions. Use the prod-
uct only as described and for the
Keep this manual safely and in the
event that the product is passed on,
hand over all documents to the third
party.
Intended Use
The petrol strimmer is intended for cutting
around trees or fence posts, and light un-
dergrowth.
Any other use not explicitly authorised in
these instructions may result in damage to
the equipment and represent a serious haz-
ard to the user.
The equipment is not designed for cutting
bushes, small trees or similar plants. The
equipment is intended for use by adults.
Young people over the age of 16 may use
the equipment only under supervision.
The manufacturer is not liable for damages
caused by use other than for the intended
purpose or by incorrect operation.
General Description
The illustration of the principal
functioning parts can be found
on the front and back foldout
pages.
Delivery Contents
Start by unpacking the equipment and
check that it is complete. Dispose of the
packaging material correctly.
• Engine housing with upper shaft tube
and unmounted multifunction handle
• Lower shaft tube
• Thread spool
• 3-toothed blade with transport protec-
tion
• 4-toothed blade with transport protec-
tion
• Protective cover
• Carrying harness with hip protector
• Service key
• 2 x hexagon socket wrench,
4 mm & 5 mm
• 2 x cable holder
• Assembly materials
• 500 ml oil/petrol mixing bottle
• Instruction Manual
Functional Description
petrol strimmer features a combustion
engine to drive the blades, which is in
operation without interruption while in use.
The power is transmitted via a clutch disc,
which uses a high-revolution centrifugal
clutch to transfer the engine output to the
strimming unit.
In the cutting process, two plastic wheels
rotate about an axis vertical to the cutting
level.
A 3- or 4-toothed blade can be mounted
as an alternative to the double thread
spool.
To protect the user, the equipment has a
protective device, which covers the cutting
device.
Please refer to the descriptions below for
how the operating parts work.
Summary
1 Engine housing
2 Spark plug connector
3 Choke lever
4 Starter handle with starter cable
5 Fuel pump (Primer)
