Parkside PBS 2 A1 User Manual

7
NI
IE
6 
7 Fuel tank
8 Top shaft tube
9 Eyelet for carrying harness
10 Multifunction handle
11 
12 Bottom shaft tube
13 Protective cover
14 Thread cutter
15 Reel capsule
16 Thread reel (not visible)
17 Operating unit
18 Device cable
19 Cable holder
20 On/off switch
21 Throttle lock
22 Throttle
23 Maintenance key
24 Hexagon socket wrench
25 500 ml oil/petrol mixing bottle
26 Carrying harness
27 Body protection
28 3-toothed blade
29 4-toothed blade
B
30 2 screws of the protective cover
31 Shaft holder
C
32 Safety lever
D
33 Star-shaped knob,
multi-functional handlebar
34 Handlebar bracket
35 Intake (+ large spring),
handlebar bracket
E
36 Tank cover
F
37 Lug of the quick-release device
H
38 Click lock, spool case
39 Thread outlet eye
40 Recess, thread spool
I
 
  
  
J
44 Spark plug
L
 
M
46 Notch in the thread spool
47 Groove in the thread spool
48 Mounting spindle
49 Washer
50 Conical spring washer
51 Nut
52 Mounting screw
53 Click lock, protective cover
54 Extension, protective cover
D
55 Spring, large
56 Spring, large
57 Screw, gear lubrication
58 Screw, eyelet
A
59 Transport protection,
3-toothed blade
60 Transport protection,
4-toothed blade
Safety Functions
21 Throttle lock
Prevents accidental acceleration
of the engine. The throttle can be
operated only when the throttle
lock is depressed.
20 On/off switch
The on/off switch switches off
the engine. It must be in position
in order to restart the engine.

Parkside PBS 2 A1 Specifications

General

Brand	Parkside
Model	PBS 2 A1
Category	Trimmer
Language	English
