21
GB IE
Please note the information on saw blade
types.
Any other use that is not explicitly ap-
proved in these instructions may result in
damage to the equipment and represent a
serious danger to the user.
The user or operator is responsible for ac-
cidents causing injury to other people or
damage to property.
This equipment is not suitable for commer-
cial use. Commercial use will invalidate the
guarantee.
General description
The illustration of the most im-
portant functional components
can be found on the front and
the back fold-out pages.
Extent of the delivery
Carefully unpack the trimmer and check
- 2 saw blades for wood (T144D) –
“Swiss Made”
- 1 saw blade for metal (T118A) –
“Swiss Made”
- 1 Allen key
- Adapter for external dust extraction
- Reducer
- Parallel guide
Dispose of the packaging material
correctly.
Description of functions
The pendulum action jigsaw has a pendu-
lum stroke device, a work light, a laser and
a parallel guide.
The notches for mitre angles allow you to
work precisely.
Please refer to the descriptions below for
information on how the operating elements
work.
Overview
1 Rotary wheel
2 Locking button
3 On/Off switch
4 Handle
5 Tool holder for Allen key
5a Mains cable
6 Adapter for external dust extraction
7 Slide shoe
8 Baseplate
9 Switch for dust blower function
10 Hexagon socket screws (not visible)
11 Pendulum stroke switch
12 Guide roller
13 Chuck
14 Slide-in openings
15 Retaining screws
16 Guard
17 Protective cover
18 Laser + LED work light (not visible)
19 On/Off switch, laser + LED work light
20 Saw blade for metal
21 Saw blade for wood
22 Allen key
23 Parallel guide
24 Reducer
25 Tension tear protection
26 Recess in slide shoe
27 Notches
