26
GB IE
Damage to a gas pipe can cause an
explosion. Penetration into a water line
causes property damage.
that is retained with clamping appli-
ances or a vice is held more securely
than with your hand.
before placing it down. The attachment
tools can jam and lead to a loss of con-
trol over the power tool.
Residual risks
Even if properly operating and handling
this electric tool, some residual risks will
remain. Due to its construction and build,
this electric tool may present the following
a) Cuts
b) Ear damage if working without ear
protection.
c) Damage to your health caused by
swinging your hands and arms when
operating the appliance for longer pe-
riods of time or if the unit is not held or
maintained properly.
Warning! During operation, this
electric tool generates an electro-
circumstances, may impair the func-
tionality of active or passive medical
implants. To reduce the risk of seri-
ous or lethal injuries, we recommend
that persons with medical implants
consult their doctor and the manu-
facturer of their medical implant
before operating the machine.
Assembly
Do not connect the device to
the power supply until it is
ready to use.
Attaching/removing the
protective cover
Attaching the protective cover
1. Press the two holders on the protective
cover (17) into the recesses on the ap-
pliance housing. The protective cover
(17) locks into place.
cover (17).
Removing the protective cover
2. Carefully press the two holders on the
protective cover (17) apart.
3. Pull the protective cover (17) to the
front.
Assembling/removing
the slide shoe
When working on scratch-sensitive work-
pieces, working with the slide shoe (7) is
recommended.
Attaching the slide shoe
1. Place the shoe (7) on the front of the
bottom plate (8).
2. Now, press the notches (27) on the
back of the slide shoe over the base-
plate (8).
Removing the slide shoe
1. Press the slide shoe (7) on the notches
(27) from the baseplate (8).
2. Pull the slide shoe (7) forward, away
from the baseplate (8).
