28
GB IE
included in delivery) in the opening
below the laser label on the front of the
device.
5. Move the screwdriver to the right to
move the laser line to the left and vice
versa.
Align the laser line centrally with the
V-shaped notch on the front edge of the
baseplate (8).
Switching on and off
Before working, check that the
laser is correctly aligned.
Adjust it if necessary.
See Chapter “Adjusting the laser”.
1. Connect the device to the mains volt-
age supply.
Switching on:
2. The rotary wheel (1) on the back of the
device has 6 levels for achieving the
desired speed.
3. Press the On/Off switch (3) to start the
device.
4. Press and hold the On/Off switch (3).
Switching off:
5. To switch off the device, release the
On/Off switch (3).
Continuous operation
6. Press the On/Off switch (3).
7. Press and hold the On/Off switch (3).
8. Press the locking button (2). You can
now release the On/Off switch (3). It is
locked.
9. To end continuous operation, press the
Pull out the mains plug if you are
leaving the device unattended or if
Adjusting the mitre
angle
1. Loosen the hexagon socket screws (10)
with the Allen key (22).
2. Press the baseplate (8) slightly backward.
3. Set the bottom plate (8) to the desired
position (-45° - 45°). A total of 7 levels
can be set (-45°, -30°, -15°, 0°, 15°,
30° and 45°).
4. Slide the baseplate (8) forward into
one of the notches.
5. Tighten the hexagon socket screws (10)
with the Allen key (22).
The maximum mitre angle can-
not be readily set on both sides.
Remove the tension tear protection
(see “Removing/attaching the ten-
sion tear protection”) and fold up
the protective cover or detach it
(see “Attaching/removing the pro-
tective cover”).
Adjusting the stroke
strength
The pendulum movement of the saw blade
can be adjusted with the pendulum stroke
switch (11). There are 4 positions for the
0 - no stroke
1 - low stroke
2 - medium stroke
3 - high stroke
The optimal stroke strength can be estab-
lished through practice; the following set-
achieved with little or no pendulum mo-
tion (level 1 or 0).
