1. Loosen the screw (
6) of the mainte-
nance cover ( 5).
2. Remove the maintenance cover ( 5).
3. Lift the compression spring (17) out of
the groove for the spring (19) the car-
bon brush (18).
4. Remove the contact plug (22) of the
contact shoe (21).
5. Pull out the brush (18) from the guide.
6. Insert a new carbon brush (18) into the
guide.
7. Place the connector (20) in a bow in
the groove for the compression spring
(19) past. Lead the connector (20)
through the side opening of the leader-
ship.
8. Slide the contact plug (22) on the con-
tact shoe (21).
9. Replace the compression spring (17)
on the nut of the compression spring
(19) the carbon brush (18).
10. Reattach the screw ( 6) the mainte-
nance cover ( 5)
11. Repeat the procedure 1 to 10 on the
other side of the unit. The carbon bru-
shes are always in pairs to share.
Storage
• Store the appliance in a dry place well
out of reach of children.
• Grinding discs must be dry and stored
upright and should never be stacked.
Waste disposal
and environmental
protection
Be environmentally friendly. Return the
tool, accessories and packaging to a recy-
them.
Electrical machines do not belong
with domestic waste.
• Hand over the device at an utilization
location. The plastic and metal parts
employed can be separated out and
thus recycled use can be implemented.
Ask our Service-Center for details.
• Defective units returned to us will be
disposed of for free.
