6772 Calorimetric Thermometer Instruction Manual
12-1
PARTS LIST
Principal Assemblies in 6772 Calorimetric Thermometer
Part Number Description
1940E Power Supply
A2141E LCD Transition Board
A2154E4 CPU Board
A2140E I/O Board
A2166E Cable, I/O to CPU USB
A2167E Cable, USB Peripheral
2147E Touchscreen LCD with Cable
1168E2 Thermistor Probe
A719E Cordset, 115V
1200EEE Corset, 220V, EU Plug
1889E Film, Display Protection
1344DD Stylus
139E23
1641E
Fuse Fast/ Act 15 Amp 250V
Fuse Fast/ Act 1.0 Amp 250V, 5 x 20 mm
WARNING: For continued protection against possible hazard,
replace fuses with same type and rating of fuse.
