8
If the car radio has a Mute input, connect the yellow wire on the mute cable to one of
the "Mute in" inputs 1, 2 or 3. Consult the car radio manual to determine the location of
the mute input.
Car radio without ISO socket
s:
A specific adapter harness for the vehicle (not supplied) may be used
If you do not have an adapter, connect the wires one by one.
If the car radio has a "mute" input, connect the yellow wire on the mute cable to it.
IMPORTANT
- The red wire on the power cable must be connected to the
12V permanent, the orange wire to the 12V switched and the
black wire to the ground.
- Check the electrical diagram of the car radio's ISO power
harness.
- On some vehicles, the positions of the red and orange
wires must be inverted. It is done by simply inverting the
fuse holders.
-Do not connect the orange wire to the 12V permanent, you
run the risk of discharging the battery of the vehicle.
User’s guide
