5
1.2 General information
1.2.1Specification
Main technical data:
Items Data Items Data
Type of engine Two cylinders,4-stroke Weight (BML/BWL/FWL) 53.7Kg/55.7Kg/54.7Kg
Displacement 362cm
3
Recommended fuel Unleaded regular gasoline
Bore X stroke 63mm×58.1mm Fuel tank capacity 24L
Gear ratio 2.08（27/13） Recommended engine oil SAE10W30 or SAE10W40
Overall length(B/FW) 988mm/665mm Engine oil quantity 1.6L
Overall width(B/FW) 420mm/430mm Recommended gear oil Hypoid gear oil SAE﹟90
Overall height (S) 1070mm Gear oil quantity 320cm
3
Overall height (L) 1197mm
Spark plug DPR7EA-9
Weight (BMS/BWS/FWS) 51.7Kg/53.7Kg/52.7Kg
Spark plug gap 0.8~0.9mm
Main performance:
Items Data Items Data
Maximum output
14.7Kw/5500rpm(20HP)
Tightening
torque for
engine
Spark plug 18.0Nm
11 Kw/5500rpm(15HP) Propeller nut 17.0Nm
Full throttle operating range 5000~6000rpm Engine oil drain bolt 28.0Nm
Idling speed (in neutral) 1050±50rpm Engine oil filter 18.0NM
Valve clearance IN(cool engine) 0.15~0.25mm
Valve clearance EX(cold engine) 0.25~0.35mm
