Parsun T5BM User Manual

1.2 General information
1.2.1 Specifications
Parameter
Items Data Items Data
Type of engine 2-stroke Weight (L) 21Kg
Displacement 102cm
3
Transom (S) 381mm
Bore X stroke 55mm×43mm Transom (L) 508mm
Gear ratio
2.08（28/13）
Recommended fuel
Unleaded regular
gasoline
Overall length 700mm Recommended engine oil 2-stroke engine oil
Overall width 310mm Recommended gear oil Hypoid gear oil SAE#90
Overall height (S) 1014mm Gear oil quantity 195 cm
3
Overall height (L) 1141mm Spark plug BPR7HS
Weight (S) 20Kg Spark plug gap
0.9～1.0mm
Performance
Items Data Items Data
(4HP) 2.9Kw/5500Rpm Idling speed (in neutral) 1050±50Rpm
(5HP) 3.7Kw/5500Rpm
Spark
plug
25.0Nm
Maximum output
(5.8HP) 4.3Kw6000Rpm
Tightening
torque
for engine
Propeller
nut
17.0Nm
Full throttle
Operating range
4500～5500Rpm
3
