TITLE : RP-300/310
Page -84 -
[Name] Print raster bit image
[Format] ASCII GS v 0 m xL xH yL yH d1...dk
Hex 1D 76 30
m xL xH yL yH d1...dk
Decimal 29 118 48 m xL xH yL yH
d1...dk
[Range] 0 ≤ m ≤ 3, 48 ≤ m ≤ 51
0 ≤ xL ≤ 255
0 ≤ xH ≤ 255
0 ≤ yL ≤ 255
0 ≤ yH ≤ 8
0 ≤ d ≤ 255
k=(xL + xH x 256) x (yL + yH x 256) (k≠0)
[Description] Selects Raster bit-image mode.
The value of m selects the mode, as follows:
m Mode Vertical Dot Density Horizontal Dot Density
0, 48 Normal 180 dpi 180 dpi
1, 49 Double-width 180 dpi 90 dpi
2, 50 Double-height 90 dpi 180 dpi
3, 51 Quadruple 90 dpi 90 dpi
[dpi : dots per 25.4mm {1” }]
·xL, xH, select the number of data bytes (xL+xH×256) in the horizontal
direction for the bit image.
·yL, yH, select the number of data bytes (xL+xH×256) in the vertical
direction for the bit image.
[Details] ·In standard mode, this command is effective only when there is no data
in the print buffer.
·This command has no effect in all print modes (character size,
emphasized, double-strike, upside-down, underline, white/black
reverse printing, etc.) for raster bit image.
·If the printing area width set by GS L and GS W is less than the minimum
width, the printing area is extended to the minimum width only on the line
in question. The minimum width means 1 dot in normal (m=0,48) and
double-height (m=2,50), 2dots in double-width (m=1,49) and quadruple
