TITLE : RP-300/310
Page -85 -
(m=3,51) modes.
·Data outside the printing area is ready in and discarded on a dot-by-dot
basis.
·The position at which subsequent characters are to be printed for raster
bit
image is specified by HT(Horizontal Tab) ESC $ (Set absolute print
position), ESC ＼ (Set relative print position), and GS L (Ste left margin).
If the position at which subsequent characters are to be printed is not a
multiple of 8, print speed may decline.
·The ESC a (Select justification) setting is also effective on raster bit image.
·When this command is received during macro definition, the printer ends
macro definition, and begins performing this command. The definition of
the command should be cleared.
·d indicates the bit-image data. Set time a bit to 1 prints a dot and setting
it to 0 does not print a dot.
GS w
n
[Name] Set bar code width
[Format] ASCII GS w
n
Hex 1D 77
n
Decimal 29 119
n
