TITLE : RP-300/310
Page -86 -
[Range] 2 ≤
n
≤ 6
[Description] Set the horizontal size of the bar code.
n
specifies the bar code width as follows:
Binary-level Bar Code
n
Module width (mm) for
Mult-level Bar code
Thin element width (mm) Thick element width (mm)
2 0.282 0.282 0.706
3 0.423 0.423 1.129
4 0.564 0.564 1.411
5 0.706 0.706 1.834
6 0.847 0.847 2.258
·Multi-level bar codes are as follows:
UPC-A, UPC-E, JAN13 (EAN13), JAN8 (EAN8), CODE93, CODE128
·Binary-level bar codes are as follows:
CODE39, ITF, CODABAR
[Default]
n
= 3
[Reference] GS k
ESC i
[Name] Execute paper full cut.
[Format] ASCII ESC i
Hex 1B 69
Decimal 27 105
[Description] When this command is received, paper is cut (only when the auto cutter is
loaded).
ESC m
[Name] Execute paper partial cut.
[Format] ASCII ESC m
Hex 1B 6D
Decimal 27 109
[Description] When this command is received, paper is cut (only when the auto cutter is
loaded).
