21
OPERATING MANUAL
CORDLESS
FRAMING NAILER
Printed in U.S.A.
© 2010 Illinois Tool Works, Inc.
405658-5
03/10
Part No. 900420
IMPORTANT
DO NOT DESTROY
It is the customer's responsibility to
have all operators and service personnel
read and understand this manual.

Table of Contents

Questions and Answers

  • J
    Jessica SharpAug 18, 2025
    What to do if Paslode Nail Gun fasteners do not drive fully?
    • C
      Christina WilsonAug 18, 2025
      If the Paslode Nail Gun operates properly but the fasteners aren't fully driven, there could be a few reasons: * The work-contacting element may require adjustment; try adjusting it. * The fuel cell might be low; check it and replace if needed. * There could be a loss of seal in the combustion chamber. To check, press the work-contacting element against the workpiece for one minute, then pull the trigger. If the fastener still doesn't drive, there's likely a leak that requires professional service.
  • G
    Gregory OdomAug 20, 2025
    Why Paslode 900420 Nail Gun operates, but no fastener is driven?
    • O
      orichardsAug 20, 2025
      If your Paslode Nail Gun operates but doesn't drive any fasteners, consider the following: * You might be using the wrong fasteners. Ensure you're using fasteners that meet Paslode specifications. * The follower might not be properly engaged behind the fastener strip. Position the follower behind the fastener strip and engage the strip. * There might be a jammed fastener. Clear the jam.
  • R
    Randy ParkerAug 22, 2025
    What to do if Paslode Nail Gun operates erratically and loses power?
    • E
      Edgar WellsAug 22, 2025
      If your Paslode Nail Gun operates erratically or seems to lose power while the indicator light is green, check the following: * The fuel cell might be low, so check it. * The spark plug wire could be loose, so inspect it. * The filter element might be dirty, causing the tool to overheat. Remove the filter element and clean it, using soap and water for stubborn debris.
  • D
    David JohnsonAug 25, 2025
    What to do if Paslode 900420 Nail Gun fan does not run and the indicator light is red?
    • M
      Mr. Gene Bird MDAug 26, 2025
      If the fan on your Paslode Nail Gun doesn't run and the tool indicator light is blinking or solid red: * The battery might not be charged; charge the battery. * The battery terminals could be oily, dirty, or corroded; clean them with fine emery cloth.
  • T
    Tony CoxAug 28, 2025
    Why Paslode 900420 battery does not accept charge?
    • D
      dwalshAug 28, 2025
      If the Paslode Nail Gun battery doesn't seem to accept a charge when plugged into the wall mount adapter: * There may be inoperative indicator lights on the charger, or a defective charger. Try the battery in the tool after a full charge cycle. If the tool LED is green, the charger isn't working properly. Replace the charger, or monitor charging time to ensure the battery has adequate time for recharging. It's normal for the battery to feel warm after properly charging. * The battery might be damaged or its cycle life exhausted. Replace the battery.
  • J
    Julie MillsAug 30, 2025
    Why Paslode Nail Gun driver blade did not return to up position?
    • K
      Kevin BerryAug 30, 2025
      If the Paslode Nail Gun operated and drove fasteners, but the driver blade did not return to the up position: * There could be built-up dirt and debris on the driver blade or in the nose bore. Clean the driver blade and nose bore with degreaser cleaner. * The mid check might be dirty or disabled. Return the tool to an authorized Paslode® Cordless dealer for service.
  • I
    icampbellSep 1, 2025
    Why my Paslode 900420 Nail Gun won't cycle but the fan runs and the light is green?
    • J
      John PerezSep 2, 2025
      If your Paslode Nail Gun's fan runs and the indicator light is solid green, but the tool won't cycle, consider these potential causes: * The fuel cell might be empty, so replace it. * The spark wire could be out of the spark plug; remove the cap, check the spark lead, insert it into the spark plug, and replace the cover. * The spark plug might be dirty; clean the tool cylinder head and spark plug.
  • N
    Nicole RosalesSep 4, 2025
    Why Paslode Nail Gun fasteners are over or under-driven?
    • A
      Ashley FarleySep 4, 2025
      If your Paslode Nail Gun sometimes over-drives and sometimes under-drives fasteners, the work-contacting element might not be adjusted properly for the material you're fastening. Adjust the work-contacting element and readjust as needed when the material's density or thickness changes.
  • M
    Matthew RogersSep 6, 2025
    What to do if Paslode 900420 Nail Gun work-contacting element does not depress fully?
    • C
      Catherine ReynoldsSep 6, 2025
      If the work-contacting element on your Paslode Nail Gun doesn't depress fully and the tool won't operate: * The lockout bracket might be stuck in the lockout position. Check the lockout. If you can't free it, return the tool to an authorized Paslode dealer for service. * The work-contacting element could be bent, or debris buildup in the track might restrict operation. Remove and inspect the lower probe, clean and lubricate the track with Cordless Lubricating oil, and repair or replace the lower probe as needed. Also, ensure the follower is positioned behind the fasteners.
  • S
    Steven EllisSep 9, 2025
    Why Paslode 900420 fan does not run and the indicator light is solid red?
    • J
      Jennifer WilliamsonSep 9, 2025
      If the fan on your Paslode Nail Gun doesn't run, or runs slower than normal, and the tool indicator light is solid red, the battery is likely discharged. Charge the battery.

Summary

Paslode Cordless Framing Nailer Operating Manual

Introduction and Warranty

About the Paslode Cordless Framing Nailer

Introduces the tool's internal combustion linear motor and its self-contained nature.

Paslode Cordless Warranty and Limitations

Details the limited warranty periods for various parts and overall tool.

An Overview of the Paslode Cordless Framing Nailer

Nailer Description and Components

Explains the tool's design, including separable handle and motor assemblies.

Technical Specifications

Lists dimensions, cycle rate, fastener types, magazine capacity, battery, and fuel cell.

Altitude Restriction

Notes potential performance loss at elevations of 4000 feet or greater.

Safety Instructions

General Safety Warnings

Covers temperature limits, combustible environments, ventilation, and child safety.

Mandatory Safety Actions

Emphasizes reading the manual and using appropriate safety gear.

Safety Instructions

Prohibited Actions and Practices

Details unsafe uses like horseplay, improper trigger use, and operating with defects.

Safe Operational Practices

Defines rules for work contact element, pointing, and fastener loading.

Safety Instructions

Work Area and Hazard Safety

Addresses concealed hazards, footing on heights, and qualified personnel.

Storage and Maintenance Safety

Covers proper fuel cell and tool storage, and keeping hands clear.

Battery and Charging System

Charging Instructions and Precautions

Step-by-step charging instructions, including initial charge and safety notes.

Battery Disposal Information

Information on proper recycling and disposal of Ni-Cd batteries.

Charging System Accessories

Lists optional accessories for the battery charging system.

Battery and Charging System

Battery Indicator Light

Explains the meaning of the LED indicator light on the tool handle.

Battery Insertion and Removal

Instructions on how to properly insert and remove the tool's battery.

Fuel Cell and Metering Valve

Fuel Cell Description

Details the fuel cell's construction, including inner and outer containers.

Metering Valve Function

Explains the metering valve's role in injecting fuel into the combustion chamber.

Altitude Effects on Fuel Cell

Notes potential impact of altitude on fuel cell propellant pressure.

Fuel Cell and Metering Valve

Installing Metering Valve to Fuel Cell

Step-by-step guide for attaching the metering valve to the fuel cell.

Fuel Cell Disposal Guidelines

Provides guidance on proper disposal of used and unused fuel cells.

Fuel Cell and Metering Valve

Inserting the Fuel Cell Assembly

Instructions for correctly inserting the fuel cell and metering valve into the tool.

Preparing the Nailer for Use

Fastener Loading and Types

Describes Paslode nails, their compatibility, and how to load them.

Lockout Feature Explanation

Explains the purpose of the lockout feature to prevent blank firing.

Weather Considerations

Details operational guidelines for hot and cold weather conditions.

Nailer Operation

Core Operation and Adjustments

Describes the nail driving sequence and adjusting nail depth.

Accessory Features

Information on optional work-contacting elements and utility hook.

Fasteners and Applications

Servicing and Maintenance

User-Serviceable Procedures

Lists procedures the user can perform, like checking battery and fuel.

Checking Battery and Fuel Cell

Instructions for checking the battery charge and fuel cell levels.

Clearing Fastener Jams

Step-by-step guide to safely remove jammed fasteners from the tool.

Servicing and Maintenance

Air Filter Maintenance

Instructions for accessing and cleaning the air filter.

Routine Post-Use Procedures

Procedures for after use, including battery charging and cleaning.

Available Tool Accessories

Lists various optional accessories for the Paslode nailer.

Required Tools

Identifies essential tools for servicing, like a hex socket wrench.

Troubleshooting

Battery and Charger Problems

Addresses issues with battery charging and charger functionality.

Normal Operation Problems

Resolves common issues during tool operation, like fan not running.

Troubleshooting

Continued Operation Problems

Addresses further operational issues like fasteners not driving fully or erratically.
