Patlite LR4 - Page 30

30
24 V DC (Class 2) (No polarity)
LR6
LED
Red
LED
Amber
LED
Green
LED
Blue
LED
White
Power Supply Wire
Buzzer
Power Supply Wire
External
Contact
Lighting/
Buzzer
External Contact Classification
Voltage Contact Relay
Fuse
1A
⑥
④
③
⑦
①
②
⑧
⑤
※ Used when buzzer unit is attached.
24 V DC (Class 2)
E
C
B
Transistor
Schematic
Fuse
1A
PLC
LR6
PLC (NPN Transistor)
External Contact Classification
LED
Red
LED
Amber
LED
Green
LED
Blue
LED
White
Power Supply Wire
Buzzer
Power Supply Wire
Lighting/
Buzzer
⑥
④
③
⑦
①
②
⑧
⑤
※ Used when buzzer unit is attached.
24 V DC (Class 2)
Fuse
1A
PLC
Transistor
Schematic
E
C
B
PLC （PNP Transistor）
External Contact Classification
LR6
LED
Red
LED
Amber
LED
Green
LED
Blue
LED
White
Power Supply Wire
Buzzer
Power Supply Wire
Lighting/
Buzzer
⑥
④
③
⑦
①
②
⑧
⑤
※ Used when buzzer unit is attached.
Point
・The flashing function cannot be used.
Output
Unit
Output
Unit
Product Specifications
Lighting / Buzzer ( LR6-WC )
